The Folksafe 4-Port 60w 10/100Mbps IEEE 802.3af/at PoE Switch supports standard Auto-MDI/MDI-X that can detect the type of connection to any Ethernet device without requiring special straight or crossover cables. When the VLAN mode is enabled, the data cannot be forwarded among DOWNLINK RJ-45 ports, but DOWNLINK ports and UPLINK RJ-45 port can communicate with each other. The bandwidth of DOWNLINK RJ-45 port is forced to 10Mbps mode to adapt to long distance transmission of max 250meters. Providing more features, more choices, gives you an easy and convenient to use product, that is plug & play, with no need to configure.
With data and power over Ethernet formed one unit, the FS-S1004EP-2E reduces cabling requirements and eliminates the need for dedicated electrical outlets on the wall, ceiling or any unreachable place. A wire that carries both data and power can lower the installation costs, simplify the installation effort and eliminate the need for electricians or extension cords.
The Folksafe 4-Port 60w 10/100Mbps IEEE 802.3af/at PoE Switch allows you to cascade your connection to better control your surveillance system. It provides both 802.3af/at PoE functions along with 4 x 10/100Base-TX ports featuring 15.4-watt 802.3af/30-watt 802.3at PoE in RJ-45 interfaces and extra 2 x 10/100Mbps UPLINK RJ-45 ports to keep a cascade connection with another switch or NVR as a kit for the administrators to centrally and efficiently manage the surveillance system in the local LAN and the remote site via the internet.
FEATURES:
- Comply with IEEE802.3, IEEE802.3u, IEEE802.3af/at standards
- Support IEEE802.3x full-duplex flow control; support Auto MDI/MDIX
- 4-Port support 48V-56VDC power to PoE powered devices
- Provide 15.4W or 30W power to powered devices
- 60-watts PoE budget
- External 53VDC/1.25A power adapter included
- Extra 2-Port 10/100Mbps UPLINK RJ-45
- PoE data & power transmission distance up to 100meters
- Port based VLAN for Enhancing Security
- Transmission distance up to 250meters while VLAN indicator turns on
- Backplane Bandwidth: 1.2Gbps
- Restart function helps master IC reset wholly
- Excellent anti-thunder, anti-static and anti-interference ability
- Surge Protection: 6KV
- Easy and convenient to use, plug & play, no need to configure
- Galvanized housing for stable and durable working life
SPECIFICATIONS:
- Housing: Galvanized
- Body Color: Black
- Power Supply Mode: Power Adaptor
- Voltage Range: DC48~56V
- Power Consumption: The device <5W, PoE power supply ≤60W
- Network Port: Ethernet Downlink RJ-45 Port: 4*10/100Mbps, Uplink RJ-45 Port: 2*10/100Mbps
- Transmission Distance: 1~4 Ethernet Downlink RJ-45 Port: 100m, Mandatory 10 Mbps reach up to 250m, Uplink RJ-45 Port: 100m
- Transmission Medium: 1~4 Ethernet Downlink RJ-45 Port: Cat5e/6 standard cable, Uplink Port: Cat5e/6 standard cable
- PoE Standards: IEEE802.3af/at
- PoE Power Supply Mode: End-span method
- PoE Power Supply Wattage: Each port ≤30W, Whole device≤60W
- Network Standards: IEEE802.3 10BASE-T, IEEE802.3u 100BASE-TX/FX, IEEE802.3az
- Swap Mode: Store-and- forward
- Data-Caching Mechanism: 448K
- MAC Address List: 1K
- Backplane Bandwidth: 1.2Gbps
- Forwarding Capacity: 0.89Mpps
- Power Indicator: Red LED on: power on
- Fast Ethernet Uplink Port: Green LED on: link up, off: link down, blinks: data transferring, Yellow LED on: link speed is 100Mbps, off: link speed is 10Mbps
- PoE Indicator: 4 PoE indicators (Yellow)
- PoE Network Port Indicator: 1~4 port indicators blink while data transferring
- Reset Button: Press the reset button to turn on indicator (green) and the device restarts.
- VLAN Button: Turn on VLAN button: indicator on and VLAN function restarts, Turn off VLAN button: indicator off and VLAN function stops
- Surge Protection: 6KV (common mode),10/700us IEC61000-4-5, 2KV (differential mode),10/700us IEC610000-4-5
- Electrostatic Protection: Contact Discharge: ±4KV, Air Discharge: ±6KV, Standard: IEC61000-4-2
- Dimensions: 16 x 9.4 x 2.7 cm
WHAT’S IN THE BOX:
- Folksafe 4-Port 60w 10/100Mbps IEEE 802.3af/at PoE Switch x1
